Features

• Stainless steel case and wetted parts
• Static pressure 10 bar or 25 bar
• Protection IP54 or IP65
• Chamber purge and bleed connection available
• High corrosive resistance
• Dry or liquid filled

Specifications

• Size: 100 mm, 160 mm
• Accuracy: 2,5 %

• Metric Range Min: 0 ... 25 mbar
• Metric Range Max: 0 ... 25 bar
• Imperial Range Min: 0 ... 10 in.H₂O
• Imperial Range Max: 0 ... 400 psi

Applications

Safety critical measuring points in Chemical and petrochemical industry, Machine and apparatus construction, Food and beverage industry, Pulp and paper industry
