Features

• Patented PowerFlexTM movement
• Rugged all welded construction
• Protection IP54 (vented) or IP65
• Overload protection 130 %
• Dry, liquid filled or liquid less (PLUS! gauge)
• Measuring system stainless steel
• True ZeroTM pointer indication
• MSL Helium leak tested
• RoHS compliant

Specifications

• Standard: ASME B40.1
• Size: 2 ½ und 3 ½ inch
• Accuracy: 1A (1 %)

• Metric Range Min: -1 ... 0 bar
• Metric Range Max: 0 ... 1000 bar
• Imperial Range Min: -30 in. Hg ... 0 psi
• Imperial Range Max: 0 ... 15.000 psi

Applications

Chemical and petrochemical industry, Machine and apparatus construction, Food and beverage industry, Pulp and paper industry
